16 CH Video Fiber Optical Media Converters -16 BNC Transmitter Receiver RS485 Data Single mode 20Km For CCTV Surveillance system

 Applications:

·         Security Systems

·         Radio and television transmission

·         Video Monitoring

·         Building control systems

·         Train/High speed road monitoring

·         Intelligent Traffic Monitoring System (ITS)

·         Remote Multimedia teaching/campus monitoring

    Long-distance radio and television transmission system

Video Index:

1.      Video : 16 channel.

2.      Video Interface: BNC.

3.      Video Input / Output Impedance : 75ohm ( unbalanced ) .

4.      Video Bandwidth 8MHz.

5.      Video format compatible PAL, NTSC, SECAM.

6.      Video voltage 1VP-P.

7.      Video SNR ≥ 70dB.

8.      Differential gain ≤ 0.7%.

9.      Differential phase ≤ 0.7 °.

10.   8- bit linear PCM coding.

11.   15MHZ high-speed sampling .

Optical index:

1. Optical Interface : FC

2. Fibre Optic: Single-mode (9/125μm)

3. Wavelength: 1310/1550μm

4. Transmission distance: single-mode fibre 0-20km.
